Trek Emonda SL Frameset, RIM BRAKE, OCLV CARBON, H2, Direct Mount,

Emonda SL Frameset

The Emonda SL Frameset is the ideal foundation for your lightweight dream build. Constructed with 500 Series OCLV Carbon, this carbon road bike frame delivers impressive climbing ability, razor-sharp handling, and a smooth, stable ride over rough roads. It’s light, fast, and ready to race.

Is This the Right Frame for You?

• You’re planning a high-performance, custom build focused on low weight and responsive handling.
• You want a carbon frameset that delivers unmatched value and performance per dollar.

Tech Highlights

• 500 Series OCLV Carbon frame with Ride Tuned performance tube shaping and seatmast
• Emonda SL full carbon fork with tapered steerer and carbon dropouts
• Internal cable routing for a clean aesthetic and improved cable longevity
• Compatible with BB90 bottom brackets and direct mount rim brakes
• DuoTrap S compatible

Why You'll Love It

• Lightweight and perfectly balanced for elite-level handling and confidence on descents
• Climbs effortlessly and stays planted in tight corners and high-speed sprints
• Internal routing improves aerodynamics and keeps your setup sleek
• Backed by Trek’s lifetime warranty for lasting peace of mind

Technical Specifications

• Frame: Ultralight 500 Series OCLV Carbon, Ride Tuned seatmast, internal routing, BB90, direct mount rim brake, 130x5mm QR
• Fork: Emonda SL full carbon, tapered carbon steerer, direct mount brake, 5x100mm QR
• Frame Fit: H2 geometry
• Headset: FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
• Seatpost: Not included
• Max Tire Size: 28mm
• Weight (56cm): 1.66 kg / 3.66 lbs
• Weight Limit: 275 lbs (125 kg) system weight (bike + rider + cargo)

Sizing Guide Size Rider Height Inseam 44 150 - 153 cm (4'11" - 5'0") 71 - 73 cm (28" - 29") 47 152 - 158 cm (5'0" - 5'2") 71 - 75 cm (28" - 30") 50 158 - 163 cm (5'2" - 5'4") 74 - 77 cm (29" - 30") 52 163 - 168 cm (5'4" - 5'6") 76 - 79 cm (30" - 31") 54 168 - 174 cm (5'6" - 5'9") 78 - 82 cm (31" - 32") 56 174 - 180 cm (5'9" - 5'11") 81 - 85 cm (32" - 33") 58 180 - 185 cm (5'11" - 6'1") 84 - 87 cm (33" - 34") 60 185 - 190 cm (6'1" - 6'3") 86 - 90 cm (34" - 35") 62 190 - 195 cm (6'3" - 6'5") 89 - 92 cm (35" - 36") 64 195 - 200 cm (6'5" - 6'7") 91 - 94 cm (36" - 37")
